MVI46-DFNT ProSoft ETHERNET MODULE

MVI46-DFNT ProSoft ETHERNET MODULE

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

MVI46-DFNT
The MVI46 EtherNet/IP (DF1 for Ethernet) Client/Server
Communication Module is an SLC backplane compatible
module that allows SLC processors to interface easily
with EtherNet/IP protocol (Explicit Messaging)
compatible devices and hosts. Devices commonly
supporting the protocol include Rockwell Automation
PLCs, and host HMI systems.
• Single Slot – 1746 backplane compatible (Local or
extended I/O rack only. Remote rack not supported)
• The module is recognized as an Input/Output
module and has access to processor memory for
data transfer between processor and module using
M0/M1 files
• Ladder Logic is used for data transfer between
module and processor. Sample ladder file included
• Configuration data obtained from configuration text
file downloaded to module. Sample configuration file
included

Specification Description
Backplane Current
Load
800 ma @ 5V (from backplane)
Operating
Temperature
0 to 60°C (32 to 140°F)
Storage Temperature –40 to 85°C (–40 to 185°F)
Relative Humidity 5 to 95% (non-condensing)
Shock 30g operational, 50g nonoperational
Vibration 5 g from 10150 Hz
LED indicators Module status, Backplane transfer
status, Application status, Serial
activity (debug port), Ethernet link
and activity, and error LED status
Debug/Configuration port (CFG)
CFG Port (CFG) RJ45 (DB-9M with supplied cable)
RS-232 only
No hardware handshaking
Configuration
Connector
RJ45 RS-232 Connector (RJ45 to
DB-9 cable shipped with unit)
Application Ports
Ethernet Port (Ethernet
Modules)
RJ45 Connector
Link and activity LED indicators
