5204-MNET-PDPMV1 ProSoft ETHERNET GATEWAY

5204-MNET-PDPMV1 ProSoft ETHERNET GATEWAY

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Specification Description
Power Supply 24 VDC nominal
18 to 32 VDC allowed
Positive, Negative, GND Terminals
2.5 mm screwdriver blade
Current Load 500 mA max@ 32 VDC max
Operating Temperature -20 to 50°C (-4 to 122°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Relative Humidity 5% to 95% (non-condensing)
Dimensions Standard: 5.20H x 2.07W x 4.52D in. (13.2cmH x
5.25cmW x 11.48cmD)
Extended: 5.20H x 2.73W x 4.52D in. (13.2cmH x
6.934cmW x 11.48cmD)

LED Indicators Power and Module Status
Application Status
Serial Port Activity LED
Serial Activity and Error LED Status
Configuration Serial Port DB-9M RS-232 only
No hardware handshaking
Ethernet Port (Ethernet modules
only)
RJ45 Connector
Link and Activity LED indicators
Electrical Isolation 1500 V rms at 50 Hz to 60 Hz
for 60 s, applied as specified in section 5.3.2 of
IEC 60950: 1991
Ethernet Broadcast Storm Resiliency = less than
or equal to 5000 [ARP] frames-per-second and
less than or equal to 5 minutes duration
Application Serial Ports RS-232/422/485
RS-232 handshaking configurable
RS-422/485 screw termination included
Serial Port Isolation 2500V RMS port signal isolation per UL 1577
3000V DC min. port to ground and port to logic
power isolation
Shipped with Each Unit Mini-DIN to DB-9M serial cables
4 ft RS-232 configuration cable
2.5mm screwdriver
CD (docs and Configuration utility)
RS-422/485 DB-9 to Screw Terminal Adaptor (1 or
4, depending on ports)
