0-54394-2 Reliance

Indications
• DC bus voltage: left LED lights when UDC > 50 V
• braking current : right LED lights when IB > 0
Switched output S1-2 (UDC > 50V)
Wearless transistor switch between terminals 1 (-) and 2 (+)
• S1-2 is closed, when UDC > 50 V and IB = 0
• S1-2 is open, when UDC > 50V and IB > 0, or when UDC < 50 V.
As shown in figure 2-4, switch S1-2 is closed after charging of the DC bus, at motor stand still or in
motoring operation mode.

AX Control Inc. is able to cover the 0-56936-103 with the automatic and comprehensive warranty that protects all of our reconditioned industrial materials in our inventory.

• 2-phase hybrid stepper motor in size NEMA 23
• Full step angle 1,8°
• M series with Sigmax® stator technology for a maximum
holding torque of up to 1,8 Nm
• P series with conventional stator design for holding torques of
up to 1,4 Nm
• Fully encapsulated stator
• Oversized bearings withstand high radial and axial loads
• Exceptional thermal dissipation
• Highest dynamics at shortest positioning times
• Optional low inertia rotor
Motor Data
Holding torque (bipolar/parallel 2 phases on) MH Nm 1,43 1,43 1,51 1,39
Rated current per winding (bipolar/parallel) I A 2,5 3,1 4,6 6,5
Technical Data
Full step 200 per resolution
Step angle ° 1,8 1,8 1,8 1,8
Angular accuracy % 3 3 3 3
Phases 2 2 2 2
Winding resistance Rph Ω 2,44 1,56 0,76 0,42
Winding inductivity Lph mH 6,2 3,9 2,1 0,8
Detent torque MP Nm 0,05 0,05 0,05 0,05
Insulation class B B B B
Insulation inductance 100MΩ @ 500VDC
Dielectricity test 500VDC 1min
Mechanical Data
Rotor inertia J Kgm2
*10-3 0,025 0,025 0,025 0,025
Mass m kg 1,13 1,13 1,13 1,13
Length Lmax mm 78,8 78,8 78,8 78,8
Ambient temperature °C -20 up to +40
Max. surface temperature °C 95
Protection class IP 23
* Please replace the x in the item number by the letter of the requested winding.
