PXC100-E.D Siemens AUTOMATION STATION

PXC100-E.D Siemens AUTOMATION STATION

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

PXC100-E.D
AUTOMATION STATION
1 AMP
24 VAC
24 VA
50/60HZ
CLASS 2
SELV/PELV
IP20(30)
MODULAR SERIES

Plug-in screw terminal Power supply Solid or stranded conductors
0.25…2.5 mm2 or 2 x 1.5 mm2
Plug-in screw terminal LonWorks bus Solid or stranded conductors
0.25…2.5 mm2 or 2 x 1.5 mm2
Simple cable lengths, cable
types (see Installation Guide
PX, CA110396)
Connection cable Ethernet and PXM20-E Max. 100 m
Cable type Standard at least CAT5
UTP (Unshielded Twisted Pair)
or STP (Shielded Twisted Pair)
Connection cable LONWORKS bus See Installation Guide CA110396
Cable type CAT5
Connection cable PXM10 Max. 3 m
Connection cables for island bus See CM110562
Housing protection standard Protection standard to EN 60529 IP 20
Protection class Insulation protection class II
Ambient conditions Normal operation To IEC 60721-3-3
Environmental conditions Class 3K5
Temperature 0...50 °C
Humidity 5…95 % r.h. (non-condensing)
Mechanical conditions Class 3M2
Transport To IEC 60721-3-2
Environmental conditions Class 2K3
Temperature -25…70 °C
Humidity 5…95 % r.h. (non-condensing)
Mechanical conditions Class 2M2
Standards, guidelines Product safety
And approvals Automatic electronic controls for
household and similar use
EN 60730-1
Electromagnetic compatibility
Interference immunity EN 61000-6-2 (industry)
Emitted interference EN 61000-6-3 (residential)
CE compliance:
Electromagnetic compatibility 2004/108/EC
UL approval (UL 916) PAZX7
Federal Communications Commission (US) FCC CFR 47 Part 15 Class B
C-Tick compliance per Australian EMC
Framework Radio Emission Standard
Radio Communications Act 1992
AS/NZS 2064
Environmental compatibility The product environmental declaration
CM1E9222 contains data on
environmentally compatible product design
and assessments (RoHS compliance,
materials composition, packaging,
environmental benefit, disposal)
ISO 14001 (Environment)
ISO 9001 (Quality)
SN 36350 (Environmentally
compatible products)
2002/95/EC (RoHS)
Dimensions See “Dimensions”
Weight Excluding packaging With packaging
All types 0,489 kg 0,531 kg
