X20CP1584 B&R I/O processor Onboard Ethernet

Item NO.:
X20CP1584
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

X20CP1584 B&R I/O processor Onboard Ethernet

Brand：B&R	Model number：X20CP1584
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: Germany
Price: Please contact us	Product weight：0.415kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Certification
CE Yes
UL 508 (cULus) LISTED 14F2 BR
ATEX Zone 2 (EX) II 3G nA nC T5 0-60°C IP20 BR
KC (KC) - BR KCC-REI-BRK-X20CP
GOST-R Yes
CPU and X2X Link supply
Input voltage 24 VDC -15% / +20%
Input current Max. 1.5 A
Fuse Integrated, cannot be replaced
Reverse polarity protection Yes
X2X Link supply output
Nominal output power 7.0 W 2)
Parallel operation Yes 3)
Redundant operation Yes
Input I/O supply
Input voltage 24 VDC -15% / +20%
Fuse Required line fuse: Max. 10 A, slow-blow
Output I/O supply
Rated output voltage 24 VDC
Permitted contact load 10.0 A
Supply - General information
Status indicators Overload, operating status, module status, RS232 data transfer
Diagnostics
RS232 data transfer Yes, using status LED
Module run/error Yes, using status LED and software
Overload Yes, using status LED and software

IF1 interface
Signal RS232
Design Connection made using 12-pin X20TB12 terminal block
Max. distance 900 m
Transfer rate Max. 115.2 kbit/s
IF2 interface
Signal Ethernet
Design 1x shielded RJ45 port
Cable length Max. 100 m between two stations (segment length)
Transfer rate 10/100/1000 Mbit/s
Transmission
Physical interfaces 10 BASE-T/100 BASE-TX/1000 BASE-T
Half-duplex Yes
Full-duplex Yes
Autonegotiation Yes
Auto-MDI / MDIX Yes
IF3 interface
Fieldbus POWERLINK (V1/V2) managing or controlled node
Type Type 4 6)
Design 1x shielded RJ45 port
Cable length Max. 100 m between two stations (segment length)
Transfer rate 100 Mbit/s
Transmission
Physical interfaces 100 BASE-TX
Half-duplex Yes
Full-duplex No
Autonegotiation Yes
Auto-MDI / MDIX Yes
IF4 interface
Type USB 1.1/2.0
Design Type A
IF5 interface
Type USB 1.1/2.0
Design Type A
IF6 interface
Fieldbus X2X Link master
Operating conditions
Mounting orientation
Horizontal Yes
Vertical Yes
Installation at elevations above sea
level
0 to 2000 m No limitations
>2000 m Reduction of ambient temperature by 0.5°C per 100 m
