TU842 ABB Shipment via DHL FedEx UPS

The TU842 MTU can have up to 16 I/O channels and 2+2 process voltage connections. Each channel has two I/O connections and one ZP connection. The maximum rated voltage is 50 V and maximum rated current is 3 A per channel.

Manufacturer : ABB

Product No. : 3BSE020850R1

Product type : TU842 Module Termination Unit

Connection : Terminal block

Channels : 16

Voltage : 50 V

Mounting : Horizontal

Mounting detail : 55 º (131 °F)

Use with I/O : AI843, AO845, AO845A, DI840, DI880, DO840, DO880 and DP840

Maximum current per I/O channel : 3 A

Maximum current process connection : 10 A

Acceptable wire sizes Solid : 0.2 - 4 mm2

Stranded: 0.2 - 2.5 mm2, 24 - 12 AWG

Recommended torque: 0.5 - 0.6 Nm

Stripping length: 7 mm

Dielectric test voltage : 500 V a.c.

Dimensions (HxWxD), approx : 18.65cm (including locking device) x 13.1cm including connector x 6.4cm including terminals

Weight : 0.6 Kg

Shipping weight : 1.5 Kg
