SCB-68A 782536-01 National Instruments Shielded I/O Connector

Item NO.:
SCB-68A 782536-01
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

SCB-68A 782536-01 National Instruments Shielded I/O Connector

Brand：National Instruments	Model number：SCB-68A 782536-01
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.16kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Relative accuracy (INL) ±2.0 LSB max
DNL ±0.9 LSB max
Monotonicity 13 bits
Voltage Output
Range ±10 V
Output coupling DC
Output impedance 0.1 Ω max
Current drive ±5 mA max
Output stability Any passive load
Protection Short-circuit to ground
Power-on state 0 V (±200 mV)

Range ±11 V
Overvoltage protection ±27 V powered on, ±12 V powered off
Input impedance 10 kΩ
Dynamic Characteristics
Slew rate 0.7 V/μs
Noise 1.0 mV , DC to 1 MHz rms
Channel crosstalk – 65 dB with SH68-C68-S cable (generating a 10 V, 100 point sinusoidal at
100 kHz on the reference channel)
Settling time 45 μs typ, 55 μs max to ±0.5 LSB
Glitch energy (at mid-scale transition)
Magnitude 400 mV
Duration 2 μs
Channel-to-channel update glitch
Magnitude 100 mV
Duration 1.2 μs
