QUINT-PS-100-240AC/24DC/40 2938879 Phoenix Power supply unit

Nominal input voltage range 110 V AC ... 240 V AC
Input voltage range 85 V AC ... 264 V AC (Derating < 100 V DC: 2.5%/V)
90 V DC ... 350 V DC (Derating < 110 V DC: 2.5%/V)
AC frequency range 45 Hz ... 65 Hz
Frequency range DC 0 Hz
Current consumption approx. 12.5 A (120 V AC)
approx. 4.5 A (230 V AC)
Nominal power consumption 1051 W
Inrush current < 15 A (typical)
Mains buffering time > 20 ms (120 V AC)
> 20 ms (230 V AC)
Input fuse 20 A (fast blow, internal)
Recommended breaker for input protection 16 A ... 20 A (Characteristics B, C, D, K)
Type of protection Transient surge protection
Protective circuit/component Varistor
Nominal output voltage 24 V DC ±1 %
Setting range of the output voltage (USet) 22.5 V DC ... 28.5 V DC (> 24 V DC, constant capacity restricted)
Nominal output current (IN) 40 A (-25 °C ... 60 °C)
POWER BOOST (IBoost) 45 A (-25°C ... 40°C permanent )
Derating 60 °C ... 70 °C (2.5%/K)
Connection in parallel Yes, for redundancy and increased capacity
Connection in series yes
Feedback voltage resistance 35 V DC
Protection against overvoltage at the output (OVP) ≤ 35 V DC
Max. capacitive load unlimited
Active current limitation Approx. IBOOST = 45 A (for short-circuit)
Control deviation < 1 % (change in load, static 10 % ... 90 %)
< 2 % (change in load, dynamic 10 % ... 90 %)
