PM865K01 ABB Processor Unit

PM865K01 ABB Processor Unit

Packaging & Delivery

Product Details

Cycle time per application programs Down to 1 ms
Flash PROMfor firmware storage 4MB
Power supply 24V DC (19.2-30 V DC)
Powerconsumption +24V typ/max 287 / 487 mA
Power dissipation typ. 6.9 W (11.4W max)
Redundant power supply status input Yes
Built-in back-up battery Lithium, 3.6 V
Clock synchronization 1 ms between AC 800Mcontrollers by CNCP protocol
Event queue in controller per OPC client Up to 3000 events
AC 800Mtransm. speed toOPC server 36-86 events/sec,113-143 data messages/sec
Comm. modules on CEX bus 12
Supplycurrent on CEX bus Max 2.4A
I/O clusters onModulebus with non-red. CPU 1 electrical, 7 optical
I/O clusters onModulebus with red. CPU 0 eletrical + 7 optical
I/O capacity onModulebus Max 96 (single PM865) or 84(red. PM865) I/O modules
Modulebus scan rate 0 -100ms (actual time depending on number of I/O modules)
Supplycurrent on Electrical Modulebus
24V : max 1.0 A
5 V : max 1.5 A
Ethernetchannels 2
Ethernet interface Ethernet (IEEE 802.3),10Mbit/s, RJ-45, female (8-pole)
Control Network protocol MMS (Manufacturing Message Service) and IAC (Inter Application
Communication)
Recommended Control Network backbone MMS (Manufacturing Message Service) and IAC (Inter Application
Communication)
Real-time clock stability 100 ppm (approx.1 h/year)
RS-232C interface 2 (one general,1 for service tool)
RS-232C interface (COM3) (non red. only)
RS-232C, 75-19 200 baud, RJ-45 female (8-pole), not opto isolated, full RTSCTS support
RS-232C interface (COM4) (non red. only)
RS-232C, 9 600 baud, RJ-45 female (8-pole), opto isolated, no RTS-CTS
suppor
