OT32E3 ABB DISCONNECT SWITCH

OT32E3 ABB DISCONNECT SWITCH

Packaging & Delivery

Product Details

Product Net Width:514 mm
Product Net Height:410 mm
Product Net Depth / Length:146 mm
Product Net Weight:32.6 kg
Technical
Rated Operational Current AC-21B (Ie):(380 ... 415 V) 3200 A
Rated Operational Current AC-22B (Ie):(380 ... 415 V) 3200 A
Conventional Free-air Thermal Current (Ith):Θ = 40 °C 3200 A
Rated Impulse Withstand Voltage (Uimp):8 kV
Rated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 1000 V
Rated Operational Voltage:Main Circuit 1000 V
Rated Short-Circuit Making Capacity (Icm):(690 V) 176 kA
Rated Short-time Withstand Current Low Voltage (Icw):for 1 s 65 kA
Power Loss:at Rated Operating Conditions per Pole 95 W
Pollution Degree:3
Handle Color:Black
Handle Type:Handle and shaft included
Switches Operating Mechanism:Mechanism at the End of the Switch
03 (Left Side)
Distance Between Phases:Standard
Position of Line Terminals:Top In - Bottom Out
Bottom In - Top Out
Operating Mode:Front operated
Standards:IEC 60947-3
Special Functions:No
Mounting Type:Base mounting
Number of Poles:3
Degree of Protection:Front IP00
Terminal Type:Lug terminals
Tightening Torque:acc. IEC 60947-1 50 … 75 N·m
Mechanical Durability:5000
Lock Type:Yes
Technical UL/CSA
Tightening Torque:acc. IEC 60947-1 50 … 75 N·m
