9233 National Instruments Analog Input Module

9233 National Instruments Analog Input Module
  • Item NO.:

    9233
  • Payment:

    T/T 、PayPal、Western Union
  • Product Origin:

    United States
  • Shipping Port:

    Xiamen
  • Lead Time:

    1-2days

Product Detail

9233 National Instruments Analog Input Module

Brand:National Instruments Model number:9233
Colour:new Warranty: 12 months
Lead Time:3-day working day Country of origin: United States
Price: Please contact us Product weight:0.18kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Number of channels..........................4 analog input channels
ADC resolution.................................24 bits
Type of ADC.....................................Delta-Sigma
(with analog prefiltering)
Sampling mode .................................Simultaneous
Internal master timebase (fM)
Frequency ...................................12.8 MHz
Accuracy.....................................±100 ppm max
Data rate range (fs
) using internal master timebase
Minimum....................................2.0 kS/s
Maximum ...................................50 kS/s
Data rate range (fs
) using external master timebase
Minimum....................................2.0 kS/s
Maximum ...................................51.3 kS/s

Common-mode voltage range
(AI– to earth ground)........................±2 V max
IEPE excitation current
Minimum....................................2.0 mA
Typical........................................2.2 mA
IEPE compliance voltage..................19 V max
Use the following equation to make sure that your configuration
meets the IEPE compliance voltage range.
Vcommon-mode + Vbias ±Vfull-scale must be 0 to 19.
where Vcommon-mode is any common-mode voltage applied to
the NI 9233,
Vbias is the bias voltage of the accelerometer, and
Vfull-scale is the full-scale voltage of the accelerometer.
Overvoltage protection (with respect to chassis ground)
For an IEPE sensor connected
to AI+ and AI– ...........................±30 V
For a low-impedance source
connected to AI+ and AI– ..........–6 to 30 V
Input delay
≤25.65 kS/s ................................12.8/fs + 3 µs
>25.65 kS/s ................................9.8/fs + 3 µs
Accuracy (–40 to 70 °C)
Calibrated typ .............................±0.1 dB
Calibrated max ...........................±0.3 dB
Uncalibrated max .......................±0.6 dB
Accuracy drift
Typical........................................0.001 dB/°C
Maximum ...................................0.0045 dB/°C
