Item NO.:
767-5801Payment:
T/T 、PayPal、Western UnionProduct Origin:
GermanyShipping Port:
XiamenLead Time：
1-2daysProduct Detail
767-5801 WAGO 8-Channel Digital Input / Output Module
Packaging & Delivery
Shipping Port: Xiamen, China
Product Details
Brand：WAGO
Model number：767-5801
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: Germany
Price: Please contact us
Product weight：0.255kg
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Module supply:
Connection type (1) M12 connectors, A coded, 4 poles;
Derating must be observed
Current carrying capacity of supply
connections max. 8 A (ULS: 4 A, UA: 4 A)
Supply voltage
Logic and sensor voltage ULS 24 V DC (-25 % ... +30 %)
Actuator voltage UA 24 V DC (-25 % ...+30 %)
Supply current
Logic and sensor current ILS typ. 45 mA (only logic part)
Actuator current IA typ. 75 mA + sensors/actuators
(max. 800 mA) + load
Protection Reverse voltage protection for ULS + UA
Short-circuit protection for sensor/actuator
supply
Digital inputs:
Number of inputs 8
Connection type (2) M8 connectors, 3 poles
Wire connection 2- or 3-wire
Input filter Hardware: ≤ 110 μs
Software: parametrizable
Input characteristic Type 2, acc. to IEC 61131-2 (767-5801)
Type 1, acc. to IEC 61131-2
(767-5801/000-800)
Signal voltage (0) -3 V ... +5 V DC
Signal voltage (1) +11 ... +30 V DC (767-5801)
+15 V ... +30 V DC (767-5801/000-800)
Input wiring High-side switching
Input voltage 24 VDC (-3 VDC < UIN < +30 VDC);
Power from UA is strongly recommended,
recovery for voltages > UA
Input current (typ.) 7.0 mA (767-5801)
3.0 mA (767-5801/000-800)
Connection of 2-wire BEROs max. 1.5 mA admissible closed current
Cable length, unshielded ≤ 30 m
