750109 Pilz SAFETY RELAY

750109
750109

750109 Pilz SAFETY RELAY

750109 Pilz SAFETY RELAY

  • Item NO.:

    750109

  • Payment:

    T/T 、PayPal、Western Union

  • Product Origin:

    United States

  • Shipping Port:

    Xiamen

  • Lead Time：

    1-2days
Inquire now
New Products

  • Product Detail

750109 Pilz SAFETY RELAY

Brand：Pilz Model number：750109
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: Germany
Price: Please contact us Product weight：0.17kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Protection type
Mounting (e.g. cabinet) IP54
Housing IP40
Terminals IP 20
Mechanical data
Housing material
Housing PC
Front PC
Cross section of external conductors with screw terminals
1 core flexible 0.25 - 2.50 mm² , 24 - 12 AWG No. 750109
2 core, same cross section, flexible:
with crimp connectors, without insulating sleeve 0.25 - 1.00 mm² , 24 - 16 AWG No. 750109
without crimp connectors or with TWIN crimp connectors 0.20 - 1.50 mm² , 24 - 16 AWG No. 750109
Torque setting with screw terminals 0.50 Nm No. 750109
Cross section of external conductors with spring-loaded terminals: Flexible with/without crimp connectors
0.20 - 2.50 mm² , 24 - 12 AWG No. 751109, 751189
Spring-loaded terminals: Terminal points per connection 2 No. 751109, 751189
Stripping length 9 mm No. 751109, 751189
Dimensions
Height 100.0 mm No. 751109, 751189
96.0 mm No. 750109
Width 17.5 mm
Depth 120.0 mm
Weight 175 g


Contact material AgCuNi + 0.2 µm Au
External contact fuse protection (IK = 1 kA) to EN 60947-5-1
Blow-out fuse, quick
Safety contacts: 10 A
Auxiliary contacts: 10 A
Blow-out fuse, slow
Safety contacts: 6 A
Auxiliary contacts: 6 A
Circuit breaker 24 VAC/DC, characteristic B/C
Safety contacts: 6 A
Auxiliary contacts: 6 A
Max. overall cable resistance Rlmax
A1/A2 20 Ohm
Input circuit 30 Ohm
Feedback loop 30 Ohm
Safety-related characteristic data
PL in accordance with EN ISO 13849-1 PL e (Cat. 4)
Category in accordance with EN 954-1 Cat. 4
SIL CL in accordance with EN IEC 62061 SIL CL 3
PFH in accordance with EN IEC 62061 2.34E-09
SIL in accordance with IEC 61511 SIL 3
PFD in accordance with IEC 61511 2.75E-05
tM in years 20
