6ES7407-0KA01-0AA0 Siemens Power supply

6ES7407-0KA01-0AA0 Siemens Power supply

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Rated value (DC)
● 120 V DC Yes; Rated value 110 V DC
● 230 V DC Yes
permissible range, lower limit (DC) 88 V
permissible range, upper limit (DC) 300 V
Rated value (AC)
● 120 V AC Yes
● 230 V AC Yes
permissible range, lower limit (AC) 85 V
permissible range, upper limit (AC) 264 V
Line frequency
● Rated value 50 Hz Yes
● Rated value 60 Hz Yes
● permissible range, lower limit 47 Hz
● permissible range, upper limit 63 Hz
● Mains/voltage failure stored energy time 20 ms
● Mains buffering according to NAMUR
recommendation
Yes

Rated value at 110 V DC 1.2 A
Rated value at 230 V DC 0.6 A
Rated value at 120 V AC 1.2 A
Rated value at 230 V AC 0.6 A
Inrush current, max. 18 A; 15 x rated value input current
Output voltage
Rated value (DC)
● 5 V DC Yes
● 24 V DC Yes
Output current
for backplane bus (5 V DC), max. 10 A; 200 mA base load required
for backplane bus (24 V DC), max. 1 A; idling-proof
Short-circuit protection Yes
Power
Active power input, typ. 105 W
Power loss
Power loss, typ. 29.7 W
Battery
Backup battery
● Backup battery (optional) Yes; 2x lithium AA; 3.6 V / 1.9 Ah
Hardware configuration
Slots
● required slots 2
Potential separation
primary/secondary Yes
EMC
Compliance with line harmonic distortion limits
● Compliance with line harmonic distortion acc. to
IEC 61000-3-2, IEC 61000-3-3
Yes
Degree and class of protection
Equipment protection class I, with protective conductor
Standards, approvals, certificates
FM approval Yes; up to 40 °C: T4
