6EP1351-1SH01 Siemens PANEL MOUNT POWER SUPPLY

6EP1351-1SH01 Siemens PANEL MOUNT POWER SUPPLY

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

6EP1351-1SH01

PANEL MOUNT POWER SUPPLY

0.41-0.22AMP

120-23V

50/60HZ

Input 1-phase AC or DC
Rated voltage value Vin rated 100 ... 240 V
Voltage range AC 85 ... 264 V
Input voltage
● at DC 110 ... 300 V
Wide-range input Yes
Overvoltage resistance 2.3 × Vin rated, 1.3 ms
Mains buffering at Vin = 187 V
Mains buffering at Iout rated, min. 40 ms; at Vin = 187 V
Rated line frequency 1 50 Hz
Rated line frequency 2 60 Hz
Rated line range 47 ... 63 Hz
Input current
● at rated input voltage 120 V 0.63 A
● at rated input voltage 230 V 0.33 A
Switch-on current limiting (+25 °C), max. 25 A
I²t, max. 0.8 A²·s
Built-in incoming fuse internal
Output Controlled, isolated DC voltage
Rated voltage Vout DC 15 V
Total tolerance, static ± 3 %
Static mains compensation, approx. 0.1 %
Static load balancing, approx. 1.5 %
Residual ripple peak-peak, max. 200 mV
Residual ripple peak-peak, typ. 10 mV
Spikes peak-peak, max. (bandwidth: 20 MHz) 300 mV
Spikes peak-peak, typ. (bandwidth: 20 MHz) 30 mV
Adjustment range 10.5 ... 16.1 V
Product function output voltage adjustable Yes
Output voltage setting via potentiometer
Status display Green LED for output voltage OK
On/off behavior No overshoot of Vout (soft start)
Startup delay, max. 0.5 s
Voltage rise, typ. 15 ms
Rated current value Iout rated 1.9 A
Current range 0 ... 1.9 A
● Note +55 ... +70 °C: Derating 2%/K
Supplied active power typical 23 W
Parallel switching for enhanced performance Yes
Numbers of parallel switchable units for enhanced
performance
2
