6AV6641-0BA11-0AX1 Siemens

6AV6641-0BA11-0AX1 Siemens Operator Panel

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

SIMATIC Operator Panel OP 77A LC display backlit, 4.5" display
graphics-capable, MPI-/PROFIBUS-DP interface to 1.5 MB,
configurable from WinCC flexible 2004 Compact HSP contains open
source software, which is provided free of charge. see enclosed CD
Product type designation OP 77A
Customer-specific configuration No
Display
Design of display STN
Screen diagonal 4.5 in
Color display No
Number of colors 2; Black/white
Resolution (pixels)
● Horizontal image resolution 160 Pixel
● Vertical image resolution 64 Pixel
Backlighting
● MTBF backlighting (at 25 °C) 100 000 h
Control elements
Control elements Membrane keyboard
Keyboard fonts
● Membrane keyboard
— user-definable label membrane keys Yes
6AV6641-0BA11-0AX1 Subject to change without notice
Page 1/
7
11/25/2019 © Copyright Siemens
● Function keys Yes
— Number of function keys 8
— Number of function keys with LEDs 4
● System keys Yes
— Number of system keys 23
● Numeric keyboard Yes
● alphanumeric keyboard Yes
● hexadecimal keyboard Yes
● Multi-key operation Yes
Touch operation
● Design as touch screen No
Connection type
● Type of connection for
mouse/keyboard/barcode reader
- / - / -
Installation type/mounting
Mounting position vertical
maximum permissible angle of inclination without
external ventilation
80°
Supply voltage
Type of supply voltage DC

Current consumption (rated value) 0.2 A
Starting current inrush I²t 0.5 A²·s
Processor
Processor type ARM
Memory
Type of memory Flash / RAM
Memory available for user data 256 kbyte
Type of output
Info LED Yes
Power LED No
Error LED No
Time of day
Clock
● Type Software clock, no battery backup
● retentive No
● synchronizable No
Interfaces
Interfaces/bus type 1x RS 422, 1x RS 485 (max. 1.5 Mbit/s)
