5069-OF4 Allen-Bradley

5069-OF4 Allen-Bradley Analog Output Module

Item NO.:
5069-OF4
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

5069-OF4 Allen-Bradley Analog Output Module

Brand：Allen-Bradley	Model number：5069-OF4
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.18kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Temperature, operating
• IEC 60068-2-1 (Test Ad, Operating Cold),
• IEC 60068-2-2 (Test Bd, Operating Dry Heat),
• IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32…140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure type rating None (open-style)
Voltage and current ratings
Analog output ratings +/–10V DC, 0…20 mA per channel
MOD power 75 mA @ 18…32V DC
MOD power (passthrough)(1)
(1) Maximum level of MOD or SA power current that the module can pass through to the next module in the system. The specific level of current passed through varies based on system configuration.
9.55 A @ 18…32V DC
SA power 150 mA @ 18…32V DC 250 mA @ 18…32V DC
SA power (passthrough)(1) 9.95 A @ 18…32V DC

Isolation voltage
250V (continuous), Basic Insulation Type
50V Functional Isolation between SA power and output ports
No isolation between individual output ports
Wire size
5069-RTB18-SCREW connections 0.5…1.5 mm2
(22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater,
3.5 mm (0.14 in.) max diameter including insulation, single wire connection only.
5069-RTB18-SPRING connections 0.5…1.5 mm2
(22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater,
2.9 mm (0.11 in.) max diameter including insulation, single wire connection only.
Insulation-stripping length
5069-RTB18-SCREW connections 12 mm (0.47 in.)
5069-RTB18-SPRING connections 10 mm (0.39 in.)
RTB torque specifications (5069-RTB18-SCREW RTB only) 0.4 N•m (3.5 lb•in)
