5069-IB16 Allen Bradley

Isolation voltage
250V (continuous), Basic Insulation Type
No isolation between SA power and input ports
No isolation between individual input ports
Wire size
5069-RTB18-SCREW connections 0.5…1.5 mm2
 (22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater, 3.5 mm
(0.14 in.) max diameter including insulation, single wire connection only.
5069-RTB18-SPRING connections 0.5…1.5 mm2
 (22…16 AWG) solid or stranded shielded copper wire rated at 105 °C (221 °F), or greater, 2.9 mm
(0.11 in.) max diameter including insulation, single wire connection only.
Insulation stripping length
5069-RTB18-SCREW connections 12 mm (0.47 in.)
5069-RTB18-SPRING connections 10 mm (0.39 in.)
RTB torque specifications (5069-RTB18-SCREW RTB only) 0.4 N·m (3.5 lb·in)
DIN rail
Compatible zinc-plated, yellow-chromate steel DIN rail. You can use the following DIN rail sizes:
• EN50022 - 35 x 7.5 mm (1.38 x 0.30 in.)
• EN50022 - 35 x 15 mm (1.38 x 0.59 in.)
North American Temp Code T4
ATEX Temp Code T4
IECEx Temp Code T4
