2868596 Phoenix Power Supplies

Item NO.:
2868596
Payment:
T/T 、PayPal、Western Union
Product Origin:
Germany
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

2868596 Phoenix Power Supplies

Brand：Phoenix Contact	Model number：2868596
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: Germany
Price: Please contact us	Product weight：0.07kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Input data

Nominal input voltage

100 V AC ... 240 V AC

AC input voltage range

85 V AC ... 264 V AC

DC input voltage range

95 V DC ... 250 V DC

AC frequency range

45 Hz ... 65 Hz

DC frequency range

0 Hz

Current consumption

Approx. 0.28 A (120 V AC)

Approx. 0.13 A (230 V AC)

Inrush surge current

< 15 A (typical)

Power failure bypass

> 15 ms (120 V AC)

> 90 ms (230 V AC)

Input fuse

1.25 A (slow-blow, internal)

Permissible backup fuse

B10

B16

Output data

Nominal output voltage

24 V DC ±1%

Output current

0.5 A (-25°C to +55°C)

0.55 A (-25 °C ... 40 °C permanent)

1 A (maximum output current)

Derating

+55°C to 70°C: 2.5% per Kelvin

55 °C ... 70 °C 2.5%/K

Connection in parallel

Yes, for redundancy and increased capacity

Connection in series

Yes

Control deviation

< 1 % (change in load, static 10% ... 90%)

< 2 % (change in load, dynamic 10% ... 90%)

< 0.1 % (change in input voltage ±10%)

Residual ripple

< 20 mVPP (20 MHz)

Peak switching voltages nominal load

< 30 mVPP (20 MHz)

Maximum power dissipation idling

< 0.3 W

Power loss nominal load max.

< 2.2 W
