2198-H040-ERS Allen-Bradley Servo Drive

Product Series    Kinetix 5500 (Bul. 2198)
Component Type Motion Control    Servo Drive
Safety Performance Level(s) (ISO13849:2006)    ISO 13849:2006 PLd ISO 13849:2006
Safety Performance Level    PLd safety
SIL Rating(s) (IEC/EN 61508)    IEC/EN 61508 SIL2 IEC/EN 61508
SIL Rating    SIL 2
SIL Claim(s) - Machinery (IEC/EN 62061)     IEC/EN 62061 SILCL2 IEC/EN 62061
SIL Claim, Machinery    SIL CL 2 machinery
Safety Category(s) (ISO13849:1999 / EN954)    EN 954 / ISO 13849:1999 Category 3 ISO 130849:1999
Safety Category    Cat 3 safety
Integration Type    Network Capable
Common DC Bus Capable    Yes Y / N
Communications Protocols    EtherNet/IP
                                               EtherNet/OCPP
Input voltage, 3ph, nom (rms)     415 V AC nom (rms)
Input Voltage, 3ph, min (rms)     324 V AC min (rms)
Input Voltage, 3ph, max (rms)     528 V AC max (rms)
Input Frequency, Nom    50 / 60 Hz
Input Frequency, Min     47 Hz
Input Frequency, Max      63 Hz
Input Current, Single Phase, Max (0 - pk)     30 A
Input Current, Three Phase, Nominal     13.4 A
Line Loss Ride Through Time      20 ms
Internal Shunt Power, Continuous     50 W
Internal Shunt Power, Peak     50 W
Internal Shunt Resistance       60 Ohms
Velocity Loop Bandwidth     300 Hz
