Item NO.:
1797-BICPayment:
T/T 、PayPal、Western UnionProduct Origin:
United StatesShipping Port:
XiamenLead Time：
1-2daysProduct Detail
1797-BIC Allen-Bradley Bus isolator module
| Brand：Allen-Bradley | Model number：1797-BIC |
| Colour：new | Warranty: 12 months |
| Lead Time：3-day working day | Country of origin: United States |
| Price: Please contact us | Product weight：0.23kg |
Packaging & Delivery
Product Details
Attribute Value
I/O module capacity 8 FLEX Ex modules(1)
Indicators Power - green when power is applied
Isolation path
Flexbus to Flexbus
Flexbus slave side
to power supply
Galvanic to DIN EN 60079-11
Galvanic to DIN EN 60079-11
Power consumption 18…32V dc @ 0.15 A
Power source failure
Max input Um = 253V ac
Power dissipation 2.1 W
Thermal dissipation 7.2 BTU/hr
IS module type [Ex ib] IIC
Conductor wire size 4 mm2
(12 gauge) stranded max
1.2 mm (3/64 in.) insulation max
Weight Approx. 200 g
Environmental conditions
Operational temperature -20…70 °C (-4…158°F)
Storage temperature -40…85 °C (-40…185 °F)
Relative humidity 5…95% noncondensing
Shock operating Tested 30 g peak acceleration, 11 (±1) ms pulse width
nonoperating Tested 30 g peak acceleration, 11 (±1) ms pulse width
Vibration Tested 5 g @ 10…500 Hz per IEC 68-2-6
Output (intrinsically safe)
(16 pin male flexbus
connector)
CENELEC
Uo < 5.75V dc
I
o < 400 mA
Po < 2.05 W
Lo < 100 μH
Co < 39 μF
Output (intrinsically safe)
(16 pin male flexbus
connector)
FM and cULus
Vt < 5.75V dc
I
t < 398.25 mA
Ca < 39.67 μF
La < 210 μH
