1769-OW8I Allen-Bradley CompactLogix Relay Output Module

Item NO.:
1769-OW8I
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

1769-OW8I Allen-Bradley CompactLogix Relay Output Module

Brand：Allen-Bradley	Model number：1769-OW8I
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.195kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Outputs 8 normally open, individually isolated (4 points/group)
Operating voltage range 5…265V AC
5…125V DC
Delay, on 10 ms
Delay, off 10 ms
Current draw @ 5.1V 125 mA
Current draw @ 24V 100 mA
Heat dissipation, max 2.83 W
Off-state leakage, max 0 mA
On-state current, min 10 mA @ 5V DC
Current per point, max 2.5 A
Current per module, max 16 A

Isolation voltage
Verified by one of these dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s, output point to bus
265V AC working voltage (IEC Class II reinforced insulation)
Verified by one of these dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s, group to group
265V AC working voltage (basic insulation)
150V AC working voltage (IEC Class II reinforced insulation)
Weight, approx 290 g (0.64 lb)
Dimensions (HxWxD), approx 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Height with mounting tabs 138 mm (5.43 in.)
Slot width 1
Module location DIN rail or panel mount
Power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating 8 modules
Terminal screw torque 0.68 Nm (6 lbin)
Retaining screw torque 0.46 Nm (4.1 lbin)
