1756-PB75 Allen-Bradley

1756-PB75 Allen-Bradley CONTROLLOGIX POWER SUPPLY

Item NO.:
1756-PB75
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

1756-PB75 Allen-Bradley CONTROLLOGIX POWER SUPPLY

Brand：Allen-Bradley	Model number：1756-PB75
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.99kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Input voltage range 18…32V DC(2) 30…60V DC(5) 90…143V DC(6)
Input voltage, nom 24V DC 48V DC 125V DC
Input power, max 85 W @ 50 °C (122 °F)
70 W @ 60 °C (140 °F) 95 W
Output power, max 60 W @ 0…50 °C (32…122 °F)
50 W @ 0…60 °C (32…140 °F) 75 W @ 0…60 °C (32…140 °F)(4)
Inrush current, max 30 A
Hold up time(1) 30 ms @18...32V DC, 60 W
40 ms @18...32V DC, 50 W
35 ms @ 18V DC
40 ms @ 24V DC
40 ms @ 32V DC
50 ms @ 30…60V DC
nom
50 ms @ 90…143V DC
nom
Current capacity @ 1.2V 1.5 A
Current capacity @ 3.3V 2 A 4 A
Current capacity @ 5.1V 8 A @ 50 °C (122 °F)
6 A @ 60 °C (140 °F) 10 A 13 A
Current capacity @ 24V 2.5 A @ 50 °C (122 °F)
2.0 A @ 60 °C (140 °F) 2.8 A
Isolation voltage
250V (continuous), Reinforced Insulation
Type, Power Input to Backplane
Type tested @ 3150V DC for 60 s
250V (continuous), Reinforced Insulation Type, Power Input to Backplane
Type tested @ 3500V DC for 60 s

Weight, approx 0.77 kg (1.7 lb) 0.95 kg (2.10 lb)
Dimensions (HxWxD), approx 14.0 x 7.8 x 14.5 cm (5.51 x 3.07 x 5.71 in.) 14.0 x 11.2 x 14.5 cm (5.51 x 4.41 x 5.71 in.)
Module location Left side of 1756 chassis
Chassis 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Chassis compatibility
Series A
Series B
Series C
Series B
Series C
Wire size 2.5 mm2
(14 AWG) solid or stranded copper wire that is rated at 90 °C (194 °F), or greater, 1.2 mm (3/64 in.) insulation max
Wire category 1 - on power ports(3)
Conductor screw torque 0.565 N•m (5 lb•in)
North American temperature code T4
