1756-OB16I Allen-Bradley

1756-OB16I Allen-Bradley ControlLogix 16 Point D/O Module

Item NO.:
1756-OB16I
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

1756-OB16I Allen-Bradley ControlLogix 16 Point D/O Module

Brand：Allen-Bradley	Model number：1756-OB16I
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.295kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Number of Outputs 16 (individually isolated)
Module Location 1756 ControlLogix Chassis
Backplane Current 350mA @ 5.1V dc & 2.5mA @ 24V dc
(1.8W Total backplane power)
Maximum Power Dissipation
(Module) 3.6W @ 60o
C
Thermal Dissipation 12.28 BTU/hr
Output Voltage Range 10-30V dc
Output Current Rating
Per Point
Per Module
2A maximum @ 30°C & 1A maximum @ 60°C (Linear derating)
8A maximum @ 30°C & 4A maximum @ 60°C (Linear derating)
Surge Current/Point 4A for 10ms each, repeatable every 2s
Minimum Load Current 1mA per point
Maximum On-State Voltage
Drop
1.2V dc @ 2A
Maximum Off-State Leakage
Current
0.5mA per point
Output Delay Time
OFF to ON
ON to OFF
1ms maximum
2ms maximum

1. All terminals with the same
name are connected together
on the module. For example,
DC(+) can be connected to
either terminal marked DC-15.
2. Do not physically connect
more than two wires to a
single RTB terminal. When
you use the second DC-15(+)
terminal to daisy chain to
other RTBs, always connect
the daisy chain as shown.
3. Outputs can be wired in a sink
or source configuration as
shown above.
4. The jumper bar part number
is 97739201. Contact your
local Rockwell Automation
sales representative to order
additional jumper bars, if
necessary.
5. If separate power sources are
used, do not exceed the
specified isolation voltage.
