1756-L82ES Allen-Bradley SAFETY CONTROLLER

Item NO.:
1756-L82ES
Payment:
T/T 、PayPal、Western Union
Product Origin:
United States
Shipping Port:
Xiamen
Lead Time：
1-2days

Inquire now

Categories

New Products

Product Detail

1756-L82ES Allen-Bradley SAFETY CONTROLLER

Brand：Allen-Bradley	Model number：1756-L82ES
Colour：new	Warranty: 12 months
Lead Time：3-day working day	Country of origin: United States
Price: Please contact us	Product weight：0.54kg

Packaging & Delivery

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Product Details

Temperature, operating (SIL 2/PLd)

IEC 60068-2-1 (Test Ae, Operating Cold),

IEC 60068-2-2 (Test Be, Operating Dry Heat),

IEC 60068-2-14 (Test Nb, Operating Thermal Shock)

0 °C ≤ Ta ≤ +50 °C (+32 °F ≤ Ta ≤ +122 °F) for Series B Chassis

0 °C ≤ Ta ≤ +60 °C (+32 °F ≤ Ta ≤ +140 °F) for Series C Chassis

Note: If operating above +55 °C (+131 °F), modules greater than 6.2 W shall not be installed in slots

adjacent to the controller.

Temperature, operating (SIL 3/PLe)

IEC 60068-2-1 (Test Ae, Operating Cold),

IEC 60068-2-2 (Test Be, Operating Dry Heat),

IEC 60068-2-14 (Test Nb, Operating Thermal Shock)

0 °C ≤ Ta ≤ +60 °C (+32 °F ≤ Ta ≤ +140 °F) for Series C Chassis

0 °C ≤ Ta ≤ +50 °C (+32 °F ≤ Ta ≤ +122 °F) for Series B Chassis

Temperature, nonoperating

IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),

IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),

IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal

Shock)

Chassis series B and C: -40…+85 °C (-40…+185 °F)

Temperature, Surrounding Air, max (SIL 2/PLd)

60 °C (140 °F) for Series C Chassis

Note: If operating above +55 °C (+131 °F), modules greater than 6.2W shall not be installed in slots

adjacent to the controller.

Temperature, Surrounding Air, max (SIL 3/PLe)

60 °C (140 °F) for Series C Chassis

50 °C (122 °F) for Series B Chassis

Relative humidity

IEC 60068-2-30 (Test Db, Unpackaged Damp Heat)

5…95% noncondensing

Corrosive Atmosphere(1) (2)

ASTM B845-97 Method H Accelerated Test (20-Day Exposure)

(1) Only applicable to modules that end with a ‘K’.

(2) Port Plugs must remain installed in unused ports at all times during storage and operation for the product to meet its corrosive atmosphere rating.

Severity Level G3 per ANSI/ISA 71.04–2013, Airborne Contaminants—Gases

Severity Level CX(3) per IEC 60721-3-3:2019, Chemically Active Substances

(3) Up to 9.6 microns per year, corrosion rate of copper.

Vibration

IEC 60068-2-6 (Test Fc, Operating)

2 g @ 10…500 Hz

Shock, operating

IEC 60068-2-27 (Test Ea, Unpackaged Shock)

30 g

Shock, nonoperating

IEC 60068-2-27 (Test Ea, Unpackaged Shock)

30 g

Emissions

IEC 61000-6-4

ESD immunity

IEC 61000-4-2

6 kV contact discharges

8 kV air discharges

Radiated RF immunity

IEC 61000-4-3

10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz

10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz

10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz

3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz

3V/m with 1 kHz sine-wave 80% AM from 2700…6000 MHz

EFT/B Immunity

IEC 61000-4-4

±2 kV at 5 kHz on Ethernet ports

Surge Transient Immunity

IEC 61000-4-5

±2 kV line-earth (CM) on Ethernet ports

Conducted RF Immunity

IEC 61000-4-6

10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MH
