1756-EN2TRK Allen-Bradley COMMUNICATIONS MODULE

Temperature, storage
IEC 60068-2-1 (Test Ab,
Unpackaged Nonoperating Cold)
IEC 60068-2-2 (Test Bb,
Unpackaged Nonoperating Dry
Heat)
IEC 60068-2-14 (Test Na,
Unpackaged Nonoperating
Thermal Shock)
-40 °C< Ta < 85 °C (-40 °F < Ta < 185 °F)
Relative humidity
IEC 60068-2-30
(Test Db, Unpackaged Damp Heat)
5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc,
Operating)
2 g @ 10…500 Hz
Shock, operating
IEC 60068-2-27
(Test Ea, Unpackaged Shock)
30 g
Shock, nonoperating
IEC 60068-2-27
(Test Ea, Unpackaged Shock)
30 g 30 g(2) 30 g(2) 30 g 50 g
Emission
CISPR 11 (IEC 61000-6-4) Class A
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine wave
80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 1890 MHz
3V/m with 1 kHz sine wave
80% AM from 2000…2700 MHz
10V/m with 1 kHz sine wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
3V/m with 1 kHz sine wave 80% AM from 2000…6000 MHz
10V/m with 1 kHz sine wave
80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 1890 MHz
1V/m with 1 kHz sine wave
80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4 — ±3 kV at 5 kHz on Ethernet ports(2) ±3 kV at 5 kHz on Ethernet
ports
±2 kV at 5 kHz on Ethernet
ports
Surge transient immunity
IEC 61000-4-5 — ±2 kV line-earth (CM) on Ethernet ports
Conducted RF immunity
IEC 61000-4-6 10V rms with 1 kHz sine wave 80% AM from 150 kHz…80 MHz
