1489-M1C030 Allen-Bradley Circuit Breaker

1489-M1C030 Allen-Bradley Circuit Breaker

Packaging & Delivery

Product Details

Catalogue No: 1489-M1C030
MCB UL489 10kA 1P 3A C CURVE
· UL 489, for branch circuit protection
· Current limiting type MCB with C and D-trip curves
· 0.5 - 63A current ratings
Component Type Power Distribution & Protection
Trip Curve
In, Rated Current at 30°C
In, Rated Current at 40°C
Poles
Rated Frequency
Un, Nominal Operational Voltage, AC
Un, Nominal Operational Voltage, DC
Impulse Withstand Test Voltage
Dielectric Strength
Electrical Service Life at Un, In
Mechanical Service Life
IP Rating, Inside
IP Rating, Outside
Flammability Rating (UL94)
Wire / Conductor Size, Rigid Cable, Top, Max
Wire / Conductor Size, Flex Cable, Top, Max
Wire / Conductor Size, Rigid Cable, Bottom, Max
Wire / Conductor Size, Flex Cable, Bottom, Max
Tightening Torque, Top, Nominal
Tightening Torque, Bottom, Nominal
Mounting
Add-On Devices (side add-on)
Padlockable
Accessories
Icu, Rated Ultimate Short-Circuit Breaking Capacity,
220/240V AC
MCB
C
3 A @30°C
3 A @40°C
1P
50 / 60 Hz
230 V AC
48 V DC
4 kV
2kV (50/60Hz, 1min) V AC
20000 cycles
20000 cycles
IP40
IP20
UL 94 V-2
35 mm² Top
25 mm² Top
35 mm² Bottom
25 mm² Bottom
2.8 Nm
2.8 Nm
DIN-35 Rail Mount
Auxiliary Contacts
Shunt Trip
Yes
Yes
15 kA @220/240VAC
